GF Type Tubular Centrifuge Separator Used To Separate Biodiesel From Glycerol

Introduction

Tubular centrifuge has been widely used in biology, pharmaceutical, health food, drinks, juice and beverage, chemical industries to separate the liquid-solid or liquid-liquid-solid materials. It is an ideal centrifuge take advantage of centrifugal methods, the minimum granules is 1 um, which is suitable for distill, condense and clarify the material has small gravity difference, small and few solid granules and high erosion products.

Working principle

The motor transmit power to the driven wheel through drive belt and tension wheel, thus for the blow to rotate around its own axis at high speed, to form a strong centrifugal force field. The material is injected inside from the liquid inlet at the bottom, and the centrifugal force compels the clarification liquid to flow upwards along the inner wall of bowl, and the clarification liquid flows out from the outlet. The solid deposit in the bowl and it will be discharged by manual after the machine is shut down.

Application

Tubular centrifuge used in a variety of biological processes: from cellular harvesting to the separation and purification of chemicals, food, blood, and even medicine.

Technical Parameters

Related popular centrifuge products
