The cold pressed VCO virgin coconut oil production line includes the following equipment: dehuller, deshelling, peeler, coconut meat grinder, coconut milk extractor, centrifuge. If the solid content of coconut milk is very less (less than 3%), you can use tubular centrifuge to extract coconut oil directly.
Introduction
The cold pressed VCO virgin coconut oil production line includes the following equipment: dehuller, deshelling, peeler, coconut meat grinder, coconut milk extractor, centrifuge. If the solid content of coconut milk is very less (less than 3%), you can use tubular centrifuge to extract coconut oil directly. If the solid content of coconut milk is very more, to receive cleared oil, you can use basket type centrifuge as prefilter, then use tubular centrifuge to to extract coconut oil.
Working principle
The cold pressed VCO production line
Application
It is especially suitable for extraction, concentration, and clarification of materials such as small relative weight difference, solid particle size, fine content, low media, and strong corrosiveness.
Technical Parameters
Model | Unit | GQ/GF45 | GQ/GF75 | GQ/GF105 | GQ/GF115 | GQ/GF125 | GQ/GF150 |
Bowl Diameter | mm | 45 | 75 | 105 | 115 | 125 | 150 |
Bowl Speed | r/min | 10000-30000 | 19000 | 16300 | 16300 | 15000 | 13400 |
Separation factor | -- | 19800 | 15200 | 15620 | 17000 | 15700 | 14300 |
Bowl Volume | L | 0.45 | 2.2 | 6 | 7 | 8 | 10 |
Throughput Capacity | L/H | 100 | 600 | 1200 | 1300 | 1500 | 2500 |
Motor | kw | 0.55 | 1.5 | 2.2 | 3.0 | 3.0 | 3.0 |
Weight | kg | 90 | 260 | 500 | 520 | 530 | 600 |
Dimension(L*W*H) | mm | 500*420*760 | 760*450*1120 | 550*850*1600 | 600*900*1600 | 650*950*1600 | 700*1000*1600 |
