Tubular centrifuge is an ideal instrument in biology, traditional medicine preparation, health food, and chemistry for liquid-solids separation. It is specially designed for the separation and clarification of process liquid with a low-density difference, small granularity, low solid content, and strong medium corrosion.
Introduction
GQ series Tubular Centrifuge from Grace Separation Machinery is a high-speed solid bowl type machine for continuously removing solids from liquid with density difference. It is an ideal instrument in biology, traditional medicine preparation, health food, and chemistry for liquid-solids separation. It is specially designed for the separation and clarification of process liquid with a low-density difference, small granularity, low solid content, and strong medium corrosion.
Working principle
GQ type tubular centrifuge is designed to separate low percentages of solids between 1 and 0.001 microns in size which are suspended in a liquid. The high centrifugal force generated causes the solids to migrate to the wall of the centrifuge tube where they are retained. The clarified liquid is discharged at the top of the tube.
Application
Tubular centrifuge used in a variety of biological processes: from cellular harvesting to the separation and purification of chemicals, food, blood, and even medicine.
Technical Parameters
Model | Unit | GQ/GF45 | GQ/GF75 | GQ/GF105 | GQ/GF115 | GQ/GF125 | GQ/GF150 |
Bowl Diameter | mm | 45 | 75 | 105 | 115 | 125 | 150 |
Bowl Speed | r/min | 10000-30000 | 19000 | 16300 | 16300 | 15000 | 13400 |
Separation Factor | -- | 19800 | 15200 | 15620 | 17000 | 15700 | 14300 |
Bowl Volume | L | 0.45 | 2.2 | 6 | 7 | 8 | 10 |
Throughput Capacity | L/H | 100 | 600 | 1200 | 1300 | 1500 | 2500 |
Motor | kw | 0.55 | 1.5 | 2.2 | 3.0 | 3.0 | 3.0 |
Weight | kg | 90 | 260 | 500 | 520 | 530 | 600 |
Dimension(L*W*H) | mm | 500*420*760 | 760*450*1120 | 550*850*1600 | 600*900*1600 | 650*950*1600 | 700*1000*1600 |
